5. SPECIFICATIONS
FRONT PANEL
6 Status LEDs
Record, Play, Stop, Rewind, FFwd, Jog
1 Power LED
3 Direction LEDs
Indicates direction of Jog Shuttle
Switches
Record, Play, Stop, Rewind, Fast Forward, Jog, Shift,Reset
DIP Switches
RECORD MODE: Lockout, Crash, Insert, Assemble
Display
2-line LCD, back lit with adjustable contrast
Jog/Shuttle Wheel
With Mechanical Detents at 1X Play Speed
Size
19” x 5” x 1-3/4” (Rackmount)
7” x 5” x 1-1/2” (Table Top)
Weight
2 lbs.
REAR PANEL CONNECTORS
RS422 Serial Out
9-Pin D-type connector, female (DB9-F)
Power
5 volt D.C., 500 ma. 90-265 VAC,
0/60 Hz converter supplied (Rack Mount or table top)
GPI
15-pin D-type connector, female (DB15F)
Switch Input: SPST contact closure, momentary
Status Output: Open collector, sink 50mA.
RS422 SERIAL CONNECTOR
9-Pin D-Type, Female (DB9-F)
Pin #
Function
1
Frame Ground
2 Receive A Í
3 Transmit B
Î
4 Transmit Common
5 Spare
6 Receive Common
7 Receive B Í
8 Transmit A Î
9 Frame Ground
