DFI NP101-D16C User Manual
Page 38
38
2
Hardware Installation
LVDS LCD Panel Connector
LCD/Inverter Power Connector
The system board allows you to connect a LCD Display Panel by
means of the LVDS LCD panel connector and the LCD/Inverter
power connector. These connectors transmit video signals and power
from the system board to the LCD Display Panel.
Refer to the next page for the pin functions of these connectors.
BIOS Setting
Configure the LCD panel in the Advanced Chipset Features
submenu of the BIOS. Refer to chapter 3 for more information.
LVDS LCD Panel
LCD/Inverter
Power
X
4 0
X
3 9
2
1
1
8
