Daktronics Display Studio Scripting Button Script Commands - Manual (Page 6)

DD2296526 Page 6 of 12
Date: 18-May-2012
To complete this action: Follow these steps when creating the script:
Step 3: Select Video
Processor Script
Step 4: See Below Step 5: See Below
Set brightness level for
video signal
Set Brightness 1
Set Video Processor
Brightness Level:
Brightness
Select Video Processor
and Channel:
Video Processor Number
Video Processor Channel
Set contrast level for video
signal
Set Contrast 1
Set Video Processor
Contrast Level:
Contrast
Set hue level for video
signal
Set Hue 1
Set Video Processor Hue
Level:
Hue
Set saturation level for
video signal
Set Saturation 1
Set Video Processor
Saturation Level:
Saturation
Set viewable area size and
alignment for incoming
video signal
Set Viewable Area
Set Video Processor
Viewable Area:
Top
Left
Height
Width
Set window area size and
alignment for sign video
signal is played on
Set Window Area
Set Video Processor
Window Area:
Top
Left
Height
Width
Set black level for selected
sign
Set Black Level
Set Video Processor Black
Level:
Black Level
Set the Z-order of Video
Impage Processor
channels
Set Z-Order
Select Video Processor
and Channel:
Video Processor Number
Video Processor Channel
Select Video Processor
Channel Z-Order (drop-
down):
Manually Set Order
Bring to Front
Send to Back
Bring Forward
Send Backward
Set frame delay for video
signal
Set Frame Delay
Set Video Processor
Frame Delay:
Frame Delay
Select Video Processor
and Channel:
Video Processor Number
Video Processor Channel
