Daktronics Display Studio Scripting Button Script Commands - Manual (Page 4)

DD2296526 Page 4 of 12
Date: 18-May-2012
To complete this action: Follow these steps when creating the script:
Step 3: Select Player
Script
Step 4: See Below Step 5: See Below
Queue setting a window to
open or close
Queue Set Window
Set Window:
Select Window (drop-
down):
Open
Close
Move
Send color correction to the
selected display
Send Color Correction
Send gamma to the selected
display
Send Gamma
Set the alpha level (opacity)
of the V-Max channel
V-Max Set Frame Alpha
Set Alpha Level:
Set Alpha Level
Set the alpha level (opacity)
of the V-Max overlay
V-Max Set Overlay Alpha
Set Overlay Alpha Level:
Set VMAX Overlay Alpha
Level
Set VMAX Overlay Color
Play a media file which
incorporates statistical data
Stats Request
Stats Request:
Request Port (drop-
down)
Data Source (drop-down)
Request Type (drop-
down)
Playmode Selection:
Continuous
Number of Times
Selected Frame
Single Step
Step 6: Select File(s)
Add File
DMP-7000 Display Control Scripts
The following table details the different types of DMP-7000 Display Control Scripts which may be created in
Display Studio. For each type of script, the table describes that script’s purpose, and shows the required steps and
available options for each step.
Step 1: Select Script Type  DMP-7000 Display Control
Step 2: Select Sign(s)
