Signal Installation
15
Section 4: Signal Installation Overview
Daktronics Galaxy ® displays are equipped to receive many types of communication. The following
sections include a brief description of each available communication type. Also included is a list of
troubleshooting tips to check that the display is connected and configured correctly.
For specific details on installing the signal, consult the quick guide and the manual. These were
included in the shipment of the communications equipment. Each type is listed below with its
manual number.
Note: These are the standard communication types. However, each site is unique and may include
additional equipment. If problems arise, contact the display’s seller, service company, or Daktronics
Customer Service.
Each of these communication types will
terminate to the location shown in Figure 17.
The signal quick-connect inputs and optional
openings are available on the left end of the
cabinet.
Communication
Type
Communication
Manual ED#
RS-422 ED-14742
Fiber ED-14743
Radio ED-13932
RS-232 ED-14739
Ethernet ED-14745
Fiber Ethernet ED-14746
Ethernet Radio ED-16483
Modem ED-14744
Figure 17: Quick-connect Signal Inputs
