Cybex 5000 Series PL - Manual (Page 186)

Service
Page 7-68
Cybex Plate Loaded Owner’s Manual
5330 - Hack Squat
1
4
4050M048
Nylon Washer .312
2
4
4113M064
Bumper
3
2
5320-204
Bearing
Sleeve
4
2
5330-332
Stop Rod Collet
5
1
5330-201
Stop Rod (Left Hand)
6
1
5330-202
Stop Rod (Right Hand)
7
4
5321-303
Pillow
Block
8
1
5330-204
Weight
Bar
9
1
5330-309
Slide
Plate
10
2
5330-312
Stop
Block
11
2
5330-313
Handle
Tube
12
8
5330M040
Plug
13
2
5330-328
Shaft 1.50 Dia. x 54.00 L
14
2
5330P029
Weight
Tube
15
4
BR030203
Linear Bearing Retaining Ring 1.50
16
4
FB110200
Linear Bearing 1.50
17
4
FS100006
O-Ring
18
4
FS110200
Linear Bearing Seal 1.50
19
6
JC620422
BHSCS .250-20 x 1.50
20
4
HC700415
BHSCS .375-16 x .75
21
10
HC702817
SHCS .375-16 x 1.00
22
6
HF449063
Insert
23
10
HN784000
Hex Nut .500-13
24
10
HS348300
Split Lockwasher .375
25
4
HS387700
Washer SAE .50
26
8
HY622910
Set Screw .250-20 x .375
27
4
JC660412
BHSCS .312-18 x .50
28
2
JC782815
SHCS .500-13 x .75
29
8
JC782820
SHCS .500-13 x 1.25
30
4
JC780426
BHSCS .500-13 x 2.00
31
14
JS388300
Split Lockwasher .50
32
2
PP080201
Plastic Insert 1.75 Dia. x 11 G
33
2
PP080202
Plastic Insert 1.19 Dia. x 11 G
ITEM QTY PART NO.
DESCRIPTION
34
2
PP090202
Plastic Insert 1.50 x 3.00 x 11 G
35
2
PU060201
Bumper
36
2
JC781222
HHCS .500-13 x 1.50
37
1
5330-200
Frame
38
1
5330-205
Carriage
39
2
JC700434
BHSCS .375-16 x 3.00
40
Removed
41
4
JC700930
FHSCS .375-16 x 2.50
42
2
JC700920
FHSCS .375-16 X 1.25
43
2
5330P012
Weight Tube 5.00
44
2
3900-447
Cybex Decal 1.94 Horiz. Black
44
2
3900-448
Cybex Decal 1.94 Horiz. Silver
44
Removed
7-03
45
2
5320-300
Non-Slip
Fabric
46
1
5330-300
Non-Slip
Fabric
47
1
5330-301
Non-Slip
Fabric
48
6
5220-367
Spacer
49
1
01215
Head Cushion with Wear Cover
50
1
4800-087
Wear
Cover
51
2
4800-071
Shoulder Cushion with Wear Cover
52
2
4800-101
Wear
Cover
53
1
01034
Back Cushion with Wear Cover
54
1
5330S055-0
Wear
Cover
55
4
PR400200
Hand Grip 14” Long
56
2
4605-501
Hand Grip 4.78” Long
57
1
5330-316
Placard
Decal
58
2
5220-337
Caution
Decal
59
1
5220-364
Warning
Decal
60
1
5330-317
Instruction Sheet (not shown)
61
2
11090-374
End
Cap
62
2
11090-376
Handle Grip Ring
63
1
51198
Strength Warranty Sheet (not shown)
64
2
JS347400
Internal Tooth Lockwasher
ITEM QTY PART NO.
DESCRIPTION
