Cybex 5000 Series PL - Manual (Page 122)

Service
Page 7-4
Cybex Plate Loaded Owner’s Manual
5221 - Advanced Overhead
1
1
4000Y316
Caution
Decal
2
4
4505-331
Bumper 1.50 Dia.
3
1
4520-212
Seat
Roller
4
2
4520-331
Roller
5
Removed
6
1
4605-334
Pivot Shaft 13.06
7
Removed
7/03
8
2
5220-305
Bumper 2.00 X 4.00
9
2
5220-367
Spacer
10
2
5220-320
Pivot Shaft 7.06
11
1
5221-200
Frame
12
1
5221-201
Bearing
Housing
13
1
5221-202
Right Hand Arm
14
1
5221-203
Left Hand Arm
15
1
5221-204
Seat
16
1
5221-316
Seat Adjustment Decal
17
1
5221-317
Placard
Decal
18
1
3900-445
Cybex Decal 1.00 Horiz. Black
18
1
Removed
7/03
18
1
3900-446
Cybex Decal 1.00 Horiz. Silver
19
2
5330M040
Plug
20
2
5362-312
Machined
Bumper
21
2
5490P010
Weight Tube 8.00
22
6
BR030210
Retaining Ring 17 mm
23
1
CM000211
Patent Pending Decal (Removed
7/6/09)
24
6
FB030232
Radial Bearing 17 mm ID
25
4
HC702815
SHCS .375-16 x .750
26
2
HC702817
SHCS .375-16 x 1.00
27
4
HC702830
SHCS .375-16 x 2.50
ITEM
QTY
PART NO. DESCRIPTION
28
4
HN704901
Nylon Locknut .375-16
29
Removed
30
1
PP090202
Plastic Insert 1.50 x 3.00 x 11 G
31
3
PP090210
Plastic Insert 2.00 SQ x 10-14 G
32
2
4605-500
Grip
6”
33
4
PP090000
Plastic Insert 1.50 x 2.00 x 11 G
34
1
JC700434
BHSCS .375-16 x 3.00
35
2
HS347600
Washer SAE .375
36
2
HC700430
BHSCS .375-16 x 2.50
37
1
4800-026
Seat
Cushion
38
1
4800-103
Back Cushion with Wear Cover
39
2
4605-508
Grip
5.50
40
4
HF449063
Tube
Insert
41
2
PP080207
Plastic Insert .437 Dia x 11 G
42
1
5220-364
Warning
Decal
43
2
5220-337
Caution Decal Load and Unload
44
1
5221-319
Caution
Decal
45
1
4800-106
Wear
Cover
46
1
4520-213
Bracket
47
1
4520-362
Caution
Decal
48
2
HS347700
Washer USS .375
49
2
JC702812
SHCS .375-16 x .50
50
4
11090-374
End
Cap
51
4
11090-376
Handle Grip Ring
52
1
51198
Strength Warranty Sheet (Not Shown)
53
4
JC620422
BHSCS .250-20 x 1.50
54
1
JC700420
BHSCS .375-20 x 1.25
55
4
JS347400
Internal Tooth Lockwasher
ITEM QTY PART NO.
DESCRIPTION
