Cybex 5000 Series PL User Manual
Page 174
Service
Page 7-56
Cybex Plate Loaded Owner’s Manual
5281 - Arm Curl
1
1
5220-364
Warning Decal
2
2
4000Y316
Caution Decal
3
2
4505-331
Bumper 1.50 Dia
4
1
4520-212
Seat Roller
5
2
4520-331
Roller
6
Removed
7
2
4535-327
Long Pivot Pin
8
2
4535-330
Pivot Handle Tube
9
2
5220-367
Spacer
10
2
5220-320
Pivot Shaft 7.06
11
1
5221-204
Seat
12
1
5221-316
Adjustable Seat Decal
13
1
5226-316
Machined
Bumper
14
1
5280-203
Front
Support
15
1
5280-204
Handle (Left Hand)
16
1
5280-205
Handle (Right Hand)
17
2
5280-206
Handle
Pivot
18
1
5281-230
Frame
19
1
5281-231
Arm (Left Hand)
20
1
5281-232
Arm (Right Hand)
21
1
5281-361
Placard
Decal
22
2
5330M040
Plug
23
2
5340P003
Weight Tube 6”
24
4
BR030210
Retaining Ring 17 mm
25
2
BR030211
Retaining Ring 1.125 Ext.
26
2
BR030214
Retaining Ring .625
27
4
FB030232
Radial Bearing 17 mm ID
28
4
FB050224
Flange Bearing 1.12 x 1.28 x .75 L
29
8
FB130205
Flange Bearing .62 x .75 x .38 L
30
2
HC702815
SHCS .375-16 x .750
31
6
HC702817
SHCS .375-16 x 1.00
32
2
HC702834
SHCS .375-16 x 3.00
ITEM
QTY PART NO.
DESCRIPTION
33
2
HN704901
Nylon Locknut .375-16
34
Removed
7-03
34
2
3900-445
Cybex Decal 1.00 Horiz. Black
34
2
3900-446
Cybex Decal 1.00 Horiz. Silver
35
2
HP286715
Groove Pin .188 x .75
36
2
HP286819
Spiral Pin .188 x 1.12
37
Removed
38
2
HS347600
Washer SAE .375
39
2
HS760102
Flat
Washer
40
2
JS407100
Machinery Bushing .625
41
1
PP090202
Plastic Insert 1.50 x 3.00 x 11 G
42
2
PP090210
Plastic Insert 2.00 Sq x 10-14 G
43
2
4605-504
Grip 5.19 L
44
1
4800-103
Back Cushion w/ Wear Cover
45
1
4800-026
Seat
Cushion
46
1
5281-004
Arm Cushion (LH) w/Wear Cover
47
1
5281-005
Arm Cushion (RH) w/Wear Cover
48
1
5281-011
Wear Cover for item #46
49
1
5281-012
Wear Cover for item #47
50
4
JC700420
BHSCS .375-16 x 1.25
51
2
JC700434
BHSCS .375-16 x 3.00
52
2
HC700430
BHSCS .375-16 x 2.50
53
1
4800-106
Wear Cover for item #44
54
4
PP080207
Plastic
Insert
55
Removed
56
Removed
57
1
4520-213
Bracket
58
1
4520-362
Caution
Decal
59
2
HS347700
Washer USS .375
60
2
JC702812
SHCS .375-16 x .50
61
1
51198
Strength Warranty Sheet (not shown)
62
8
JS347400
Internal Tooth Lockwasher
ITEM QTY PART NO. DESCRIPTION
