Cybex 5000 Series PL - Manual (Page 182)

Service
Page 7-64
Cybex Plate Loaded Owner’s Manual
5321 - Leg Press
1
2
4113M064
Bumper
2
1
5321-201
Left Hand Stop Rod
3
1
5321-202
Right Hand Stop Rod
4
4
5321-303
Angle
5
2
5320-204
Bearing
Sleeve
6
1
5320-208
Weight
Bar
7
2
5320-332
Stop Rod Collet
8
2
5321-302
Shaft 1.50 Dia. x 50.00 L
9
1
5320M042
Cable
17.00
10
2
5320P040
Detent
Pin
11
8
5330M040
Plug
12
2
5330P029
Weight
Tube
13
4
BR030203
Linear Bearing Retaining Ring 1.50
14
2
BS070201
Com Spring .56 x .66 x 1.50 L
15
4
FB110200
Linear Bearing 1.50
16
4
FS100006
O-Ring
17
4
FS110200
Linear Bearing Seal 1.50
18
10
HC702817
SHCS .375-16 x 1.00
19
10
HN784000
Hex Nut .500-13
20
4
HN814400
Jam Nut .625-11
21
10
HS348300
Split Lockwasher .375
22
6
HS387700
Washer SAE .50
23
4
HY582910
Set Screw #10-32 x .19 Cup Pt
24
8
HY622910
Set Screw .250-20 x .375
25
4
JC660412
BHSCS .312-18 x .50
26
6
JC780420
BHSCS .500-13 x 1.25
27
2
JC782815
SHCS .500-13 x .75
28
4
JC782817
SHCS .500-13 x 1.00
29
6
JC782820
SHCS .500-13 x 1.25
30
2
JD423338
S/Bolt .75 x 3.50 .625-11
31
16
JS388300
Split Lockwasher .50
ITEM
QTY
PART NO.
DESCRIPTION
32
2
JC700420
BHSCS .375-16 x 1.25
33
8
JS427600
Washer SAE .75
34
2
PP080201
Plastic Insert 1.75 Dia x 11 G
35
2
PP080202
Plastic Insert 1.19 Dia x 11 G
36
2
PP080207
Plastic Insert .437 Dia x 11 G
37
2
PP470006
Oval
Knob
38
2
PU060201
Bumper
39
1
5320-200
Frame
40
1
5320-205
Side
Plate
41
1
5320-206
Platform
42
1
5321-203
Seat
43
1
5320-301
Non-slip
Fabric
44
4
HC700426
BHSCS .375-16 x 2.00
45
2
5330P012
Weight Tube 5.00
46
Removed
9/04
47
2
3900-447
Cybex Decal 1.94 Horiz. Black
47
2
3900-448
Cybex Decal 1.94 Horiz. Silver
47
Removed
7-03
48
2
5320-300
Non-slip
Fabric
49
6
5220-367
Spacer
50
1
5321-011
Back
Cushion
51
1
4800-024
Seat
Cushion
52
1
5320-336
Back Pad Adjustment Decal
53
1
5320-346
Warning
Decal
54
1
5321-598
Placard
Decal
55
1
55321
Leg Press Bar Assembly Inst.
56
2
5220-337
Caution
Decal
57
1
5220-364
Warning
Decal
58
2
PR400204
Grip 4.78 L
59
1
51198
Strength Warranty Sheet (not shown)
60
6
JS347400
Internal Tooth Lockwasher
ITEM QTY PART NO.
DESCRIPTION
