Cybex 5000 Series PL User Manual
Page 178
Service
Page 7-60
Cybex Plate Loaded Owner’s Manual
5286 - Arm Extension
1
Removed
7-03
1
2
3900-445
Cybex Decal 1.00 Horiz. Black
1
2
3900-446
Cybex Decal 1.00 Horiz. Silver
2
2
4000Y316
Caution
Decal
3
2
4505-318
Counterweight
4
2
4505-331
Bumper 1.50 DIA
5
1
4520-212
Seat
Roller
6
2
4520-331
Roller
7
Removed
8
2
4540-321
Handle
Bumper
9
Removed
7-03
10
2
5220-367
Spacer
11
2
5220-320
Pivot Shaft 7.06
12
1
5221-204
Seat
Support
13
1
5221-316
Seat Adjustment Decal
14
1
5226-316
Machined
Bumper
15
2
5255-204
Weight
Tube
16
1
5280-203
Front
Support
17
1
5285-253
Pull Handle (Left Hand)
18
1
5285-254
Pull Handle (Right Hand)
19
1
5286-240
Frame
20
1
5286-241
Arm (Left Hand)
21
1
5286-242
Arm (Right Hand)
22
1
5286-342
Placard
Decal
23
2
5330M040
Plug
24
4
BR030210
Retaining Ring 17 mm
25
2
BR030211
Retaining Ring 1.125 Ext.
26
4
FB030232
Radial Bearing 17 mm ID
27
4
FB050224
Flange Bearing 1.12 x 1.28 x .75 L
28
2
HC702815
SHCS .375-16 x .750
29
2
HC702817
SHCS .375-16 x 1.00
30
2
HF449063
Connector Insert 3/4 x1/4-20
31
2
HC702834
SHCS .375-16 x 3.00
32
2
HN704901
Nylon Locknut .375-16
33
2
PP090210
Plastic Insert 2.00 Sq x 10-14 G
34
Removed
35
1
4800-106
Wear Cover for item #40
36
2
HS347600
Washer SAE .375
37
1
PP090202
Plastic Insert 1.5 x 3.0 x 11 G
38
2
4605-500
Grip 6” L
39
4
PU060203
Bumper
40
1
4800-103
Back Cushion w/ Wear Cover
41
1
4800-026
Seat
Cushion
42
1
5281-004
Arm Cushion (LH) w/Wear Cover
43
1
5281-005
Arm Cushion (RH) w/ Wear Cover
44
1
5281-012
Wear Cover for item #43
45
1
5281-011
Wear Cover for item #42
46
4
JC700420
BHSCS .375-16 x 1.25
47
2
JC700434
BHSCS .375-16 x 3.00
48
2
HC700430
BHSCS .375-16 x 2.50
49
Removed
50
1
5220-364
Warning
Decal
51
1
4520-213
Bracket
52
1
4520-362
Caution
Decal
53
2
HS347700
Washer USS .375
54
2
JC702812
SHCS .375-16 x .50
55
2
11090-374
End
Cap
56
1
51198
Strength Warranty Sheet (not shown)
57
2
JC620422
BHSCS .250-20 x 1.50
58
8
JS347400
Internal Tooth Lockwasher
ITEM QTY
PART NO.
DESCRIPTION
ITEM QTY
PART NO.
DESCRIPTION
