1.4 Regulatory Compliance
UL 1950 listed
cUL listed per CSA 22.2 No. 950-95
IEC 950 classified
CFR
47, Part 15 Class A
CE Mark
1.5 Power Requirements
Electrical
MODHUB-16 series MODHUB-48 series
Input voltage: 100 VAC to 230 VAC 100 VAC to 230 VAC
(+/–10%) (+/–10%)
Input current: 0.5 amps max 1.0 amps max
Input frequency: 47 Hz to 63 Hz 47 Hz to 63 Hz
Input fuse(s): 1 amp slo blo 1 amp slo blo
5 mm x 20 mm 5 mm x 20 mm
1.6 Ordering Information
Select an adequately sized MOD HUB for the number of ports
required. The MODHUB-16 has four slots and can support up
to 16 ports. The MODHUB-48 has twelve slots and can support
up to 48 ports. EXP expansion modules generally support four
ports each and are ordered separately. Refer to EXP data sheets
for detailed information.
MOD HUB “E” designation means export model and is shipped
with a continental Europe power cord. These units have two
input fuses to address unpolarized power systems and carry the
CE Mark. This model can be modified at the factory for single
fuse operation if requested.
MOD HUB “F” designation means flange-mounted enclosure
which is standard for panel-board mounting. For rack mounting,
do not specify the “F” designation, but order a MTG-RAK
instead. The MTG-RAK supports either two MODHUB-16s
(-16Es) or one MODHUB-48.
