Digicast Micro Encapsulator (MENCAP) Revision A
Installation & Initial Configuration MN/MENCAPEDC.IOM
2.4.2 Redundancy Configuration
The initial configuration involves setting up the IP parameters via the terminal cable.
The MENCAP Redundancy comes preconfigured – simply configure the IP address for
both the Primary and Secondary units.
Once the IP parameters have been configured, the terminal cable can be removed and
should be stored in a known location, since it may be needed in the future.
To configure the IP parameters:
Step Procedure
1 Using a terminal emulator on a PC such as HyperTerminal™ or TeraTerm™,
set up the communication port as follows:
• 38,400 BAUD
• 8 Data Bits
• 1 Stop Bit
• No Parity
• No Flow Control
2 Press the key on the PC – the MENCAP 50’s menu should be
displayed.
3 Press “N” for Network Menu.
4 Press “I” for the IP Address. Enter the IP Address and press .
5 Press “M” for the Subnet Mask. Enter the Subnet Mask and press .
6 Press “G” for the Default Gateway IP Address. Enter the Default Gateway
Address and press .
7 Press “S” to save the parameters, then press to confirm the changes.
8 Press “X” to exit to the main menu.
9 Press “Y” to edit the redundancy information.
10 Press “1” to enter the Backup unit IP address. Press when finished.
11 Press “2” to check for the Backup unit MAC address – it should already be there.
Press to confirm the selection.
12 Press “M” to set mode “Primary for Left unit Backup for Right unit,” then press
to confirm the selection.
13 Press “S” to save the parameters, then press to confirm the changes.
14 Press “X” to exit to the main menu.
15 Press “E” to configure the egress port.
16 Press “C” to configure the egress clock rate.
17 Enter the egress rate in megabits per second (Mbps) and press .
18 Press “P” to configure PSI parameter only if needed. The default selection is NO.
19 Press “X” to exit the menu.
20 Press “S” to save the parameters.
21 Press “X” to exit the menu.
22 Repeat steps 1 through 14 in this section to configure the Backup (secondary)
unit.
