3.3 RFT Installation
The RFTs can be installed anywhere on or near the antenna. The supplied hardware
allows the installer a wide range of installation alternatives, including:
• Vertical pole (e.g., mast) (either square or round). This is the most typical
installation.
• Within the hub of a large antenna.
• Spar (i.e., rectangular bar) on the antenna structure.
EFData recommends that the RFTs be mounted vertically, with the air inlets facing
downward.
