Remote Control Operation
CST-5000 C-Band Satellite Terminal
B–6
Rev. 9
Select
Preset
Config
Command:
Response:
Status:
Response:
Where: n = 1, 2, or 3.
1
UCF_nnnn.n'cr'
nnnn.n = 5845.0 to 6425.0 MHz.
DCF_nnnn.n'cr'
nnnn.n = 3620.0 to 4200.0 MHz.
UCA_nn.n'cr'
nn.n = 0.0 to 25.0 dB (UC Fine Adj).
DCA_nn.n'cr''lf']
nn.n = 0.0 to 21.0 dB (DC Fine Adj).
2
UCF_nnnn.n'cr'
nnnn.n = 5845.0 to 6425.0 MHz.
DCF_nnnn.n'cr'
nnnn.n = 3620.0 to 4200.0 MHz.
UCA_nn'cr'
nn.n = 0.0 to 25.0 dB (UC Fine Adj).
DCA_nn'cr''lf']
nn.n = 0.0 to 21.0 dB (DC Fine Adj).
3
UCF_nnnn.n'cr'
nnnn.n = 5845.0 to 6425.0 MHz.
DCF_nnnn.n'cr'
nnnn.n = 3620.0 to 4200.0 MHz.
UCA_nn'cr'
nn.n = 0.0 to 25.0 dB (UC Fine Adj).
DCA_nn'cr''lf']
nn.n = 0.0 to 21.0 dB (DC Fine Adj).
Allows the user to select any one of three 'Preset'
configurations. The users must first program (store) a
configuration using the 'PGM_n' command defined below. This
command used without the 'Preset' number (n) will provide the
current programming of each of the three 'Presets.'
Program
Preset
Config
Command:
Response:
Status:
Response:
Where: n = 1, 2, or 3.
1
xxxxxxxxxx'cr''lf']
xxxxxxxxxx = 'Programmed' or 'None'.
2
xxxxxxxxxx'cr''lf'].
3
xxxxxxxxxx'cr''lf'].
Allows the user to store (program) the current frequency and
attenuator settings as one of three 'Preset' selections.
Clear
Program
Preset
Config
Command:
Response:
Status:
Response:
Where: n = 1, 2, or 3.
1
xxxxxxxxxx'cr''lf']
xxxxxxxxxx = 'Programmed' or 'None'.
2
xxxxxxxxxx'cr''lf'].
3
xxxxxxxxxx'cr''lf'].
Allows the user to clear (unprogram) the frequency and
attenuator setting for one of three 'Preset' selections.
Lock Mode
Command:
Response:
Status:
Response:
Where: xx = LK (lock) or EN (default, enable).
Lock mode prevents the current settings from being changed.
RS-232-C
Address
Select
Command:
Response:
Status:
Response:
Where:
add = current address.
xxx = new address, 1 to 255.
Default address = 1.
