2.
SINGLE THREAD SYSTEM
INSTALLATION
This chapter provides installation information for single thread systems, including:
• Unpacking and inspecting the parts
• Installing the RFT
• Installing the LNA
• External connections
For redundant systems, refer to Chapter 3.
2.1 Unpacking
The CST-5000 terminal system is packaged in preformed, reusable foam inside a
cardboard carton.
Before unpacking the carton components, ensure that there is plenty of working space
around the carton; a large table is recommended.
To remove the parts:
1. Cut the tape at the top of the carton where it is labeled ‘OPEN THIS END’.
2. Lift out the cardboard/foam spacer covering the unit.
3. Remove each part from the carton. Refer to Section 2.2.1 for a parts breakdown.
CAUTION
Because the RFT is heavy, assistance may be necessary to remove
the unit from the box.
Note: Save the packing material for reshipment/storage.
Chapter
