Installing the DES-5016
12
Rack Installation
The DES-5016 can be mounted in an EIA standard size, 19-inch rack. The dimensions of
the DES-5016 are 4.4 inches (112 mm) x 10.39 inches (264 mm) x 17.32 inches (440
mm). The DES-5016 can be placed in a wiring closet along with other equipment.
Follow these steps to install the DES-5016 on a rack:
1. Attach a mounting bracket to each side of the DES-5016 with the screws provided.
See Figure 7.
2. Slide the DES-5016 into the rack and use the screws provided to secure the DES-
5016 to the rack. See Figure 8.
3. Connect the power cord and verify that the DES-5016 is receiving adequate power.
Figure 7: Attach Mounting Brackets
