Rear panel – D-Link DES-5016 User Manual
Page 14
Fast Ethernet Switching System User’s Guide
Introduction
6
Rear Panel
The three pronged power plug, ventilation fan and the on/off switch are located at the rear
of the DES-5016 displayed in Figure 4. The switch will work with AC in the range 100-
240 VAC, 50-60 Hz. The power requirements are indicated on the rear panel of the DES-
5016. When installing the DES-5016, leave enough room to allow you to plug in the
power cable.
There are heat vents located on the sides. The fans and the vents help to cool the DES-
5016. Always leave two inches of space around the DES-5016 so that air can circulate
and cool the DES-5016.
