D-Link DES-5016 User Manual
Page 18
Fast Ethernet Switching System User’s Guide
Installing the DES-5016
10
Desktop/ Shelf Installation
The dimensions of the DES-5016 are 4.72 inches (120 mm) x 10.39 inches (264 mm) x
17.32 inches (440 mm). These measurements include the 8-mm rubber feet provided with
the DES-5016.
Follow these steps to install the DES-5016 on a desktop or shelf:
1. Place the four rubber feet at the corners of the DES-5016. See Figure 5 and Figure 6.
2. Place the DES-5016 on the desktop/shelf.
Figure 5: Install Feet on Bottom
