42
UK
The company supplying this machine cannot
be held liable for any damage arising from
incorrect installation, insufficient or lack of
maintenance, or improper use of the appliance.
• Legal standards and connection instructions
from the local electricity supplier must be
respected.
• Before making electrical connections, make
sure that the electrical capacity of the sys-
tem is suitable for the maximum power of
the appliance, as indicated on the rating
plate.
• When making connections or repairs, it is
necessary to disconnect the appliance from
the mains electricity.
• When the appliance is assembled, it must
not be possible to touch any insulated
cables enabling appliance operation.
• The appliance is equipped to be connected
to a single plug socket, which must be fitted
in full compliance with the standards in
force. Only a qualified electrician may install
a plug socket or replace the power cord,
which must be performed in full respect of
the standards in force.
• If, after connection, it is no longer possible
to reach the plug, a separator with more
than one pole and a contact distance of at
least 3 mm must be fitted in order to comply
with safety regulations.
• The unit housing the built-in coffee machine
5.
ASSEMBLY INSTRUCTIONS FOR QUALIFIED PERSONS
5.1 INSTRUCTIONS FOR
BUILT-IN ASSEMBLY
must be suitably fixed to the floor or wall in
the room.
• To guarantee safe machine use, the unit
housing the machine must be structurally
sound and its guide attachment points must
be able to sustain a weight of three times
that of the coffee machine during the
removal phase.
5.2 CM400FA BUILT-IN UNIT
DIMENSIONS
A 600 mm A 23,62 Inc
B da 562 a 568 mm B 22,13 - 22,36 Inc
C 450 mm C 17,72 Inc
D da 16 a 19 mm D 063 - 075 Inc
SCM5
