User Manual
51
Type
Device Parameter
SVR9000D/T8
Video / Audio
Video System
PAL/NSTC（Optional）
Compression Format
G.711A(Audio)/H.264(Video)
Display Resolution
D1：704×576(PAL) 704×480 (NTSC)
Record Resolution
D1/HD1/CIF:Each channel could be set separately
Record Frame Rate
PAL : 200 fps@D1 NSTC : 240 fps@D1
Display mode
Support auto sequence ,PIP Mode and Zoom in/out in special
area
Record
Record mode
Always, Scheduled, motion, Alarm, Net-viewer record.
Pack Time
15/30/45/60 min (adjustable)
Playback mode
Normal play,Fast Forward,Rewind and slow play frame by
frame.
Backup
Support U flash disk, removable HDD, recorder and network
backup
Alarm
Alarm mode
Motion Detection, Sensor triggered, Video Loss, HDD Full,
HDD Error
Network
Network Function
Support Mobile surveillance, Remote Live surveillance and
parameter setting.
Network Protocol
Supports TCP/IP, DHCP, UDP, DDNS, PPPOE network
Protocol
System
Interface
Video input/output
4CH Input / 2CH Output；1CH VGA output；HDMI Output
Audio input/output
4CH Input / 2CH Output
Alarm input/output
8CH Input / 1CH Output
HDD Interface
Support USB removable HDD and SATA HDD
Network Interface
One RJ-45 10M/100M self-adaptable Ethernet interface
USB Interface
Support USB2.0 Mouse, removable HDD and U flash disk
backup and upgrade.
PTZ Control
Embedded RS-485 port, supports PELCO-P & PELCO-D
General
Parameter
Power Adapter
DC 12V 3A
Operational Temperature 10℃~+40℃
Operational Humidity
10%~90%
Power Consumption
≤
10W
Dimension (Lx W x H)
315×234×58mm
List 7-2
