User Manual

Alarm Type

Function

Video Loss

Sends alarm when DVR can’t receive video signal (such as camera damage, cable broken

or damaged or power supply malfunction).

Motion

Detection

When an object moves into motion detection area, alarm will be triggered. You can

adjust sensitivity level to suit the needs of your actual application environment.

I/O Status

System can convert alarm signal triggered by external sensor into signal identified

by system.

HDD loss

When Hard Drive is not detected (HDD damage, power supply malfunction), or HDD

auto-overwrite is off, and free space is not enough, an alarm will be triggered.

5.3.5.3 Motion Detection

5.3.5.4 Vehicle Setup

Record LP: allows you set if the license plate number display on the recorded data or not.

Preview LP: allows you set if the license plate number appear on Live screen or not.

Record GPS: allows you set if the GPS info display on the recorded data or not.

Preview GPS: allows you set if the GPS info appears on Live screen or not.

5.3.5.5 PTZ Setup

You can set up motion detection in a specific area for one camera.

Click [Main Menu

Device Management

Motion Detection] to enter

into the below interface shown as Picture 5-19.

Channel Status: Video motion detection can be turned on or off for

each camera.

SENSITIVITY: This option allows you to set sensitivity level of motion

detection from 1 to 4 with 4 being the most sensitive.

List 5-1

Picture5-20

MD Area: This option allows you setup the MD area for the channel

you wish to be sensitive to motion. The channel will be separated into

a 13X10 grids. When any object moves into the motion detection

area, and the area where the object is located is displayed in red and

motion detection will be triggered. In the semi-transparent area the

motion detection is not activated.

License Plate: you can set the car license plate here and the model

supports the plate with Chinese character.

Speed Measurement From: allow you get speed measurement source

from GPS signal or Sensor signal

Delay power off: you can set how long DVR is delayed power off after

car ignition is off. Options include

30min, 40min, 50 min and 60min>.

Picture5-19

Picture 5-21

Picture 5-22

Note: If user want to perform speed measurement by sensor, please

connect one wiring in green provided to speed sensor firstly

When car starts to move, enter into [Parameter setting] option and

click [Start] button to start speed measurement, and click [Stop] button

till car have been driving for one km, and then click [Save]button to save

and exit the [parameter setting] menu.
