1.2. Operating elements of the key bar (control panel)
For the input and output of data, the machine is equipped with a key
bar
including an 8-digit display, which is divided into 3 distinct blocks.
Display
During the standard programme run, the display is structured as
follows:
left 3 digits: sewing machine class
centre 2 digits: no display
right 3 digits: piece counter
If a test programme is activated, the display shows various other
parameters.
Key/
key groups
Function
Key for the selection of a function
S Start key for the infeed of a template
Key for the selection of a function
ESC Cancellation of sewing process/sewing machine is
reset to initial position
OK Confirmation of an entry
0 to 9 Entry of numerical values
á Modification of settings in indicated direction
â
Modification of settings in indicated direction
F1, F2,
F3, F4 Function keys
