Hardware Preparation and Installation

COMX-P2020 COM Express Module Installation and Use (6806800K97D)

2.1.3

Power Requirements

The default power input setting for COMX-P2020 is 12 V (11.4 - 12.6).

2.2

Default Settings

The following table shows the default settings of COMX-P2020 COM-E module:

Table 2-3 Module Total Power Consumption

Voltage

+12V POWER

Power consumption

12 W (when idle in Linux)

Table 2-4 Default Settings

Component Value

COM-E Power Input

12 V (11.4-12.6)

CPU (speed)

1.2 GHz

Memory (speed)

667 MHz

PCI-E

PCIE 2(x1)(2.5Gbps) SerDes lane 1

PCIE 3(x2)(2.5Gbps) SerDes lane 2-3
