25B
Tahoma DE-4 / DE-8
Table 19: Tahoma DE-4 / DE-8 Physical Specifications
Size
H: 1.75 in (4.45 cm, 1RU)), W: 18 in (21.6
cm), D: 13 in (33 cm)
Rack installation Standard 19-inch equipment rack.
Weight 12 lbs. (2.8kg)
Power 90/250 VAC, 60/50Hz, 100 W, internal auto
switchable
Noise Level Maximum 38dB. Tahoma LE has temperature
sensor to regulate fan speed, actual noise
level may be much lower
Figure 17 - 18 shows the front and back panels of the Tahoma DE-4 / DE-8.
Figure 17: Tahoma DE-4 / DE-8 front panel view
Front Panel indicators, connectors and buttons are:
1. Signal presence LED
2. Power supply status
3. Audio volume adjustment
4. Audio phone jack output
5. Paging mode
6. Buttons to recall presets
