Table 5: Display Output
Standards
DVI-D, HDMI 1.2/3, VGA up to 2048x1080,
SDI
Connector
RJ45 (with transmitter), BNC
Impedance
100Ω, 75Ω
Table 6: Audio Outputs
Type Number/type/connector Location Adjustment
AES
1 / unbalanced / BNC
Rear Panel
None, Line Level
Stereo Analog
1 / unbalanced / phone jack
Rear Panel
None, Line Level
Stereo Analog
1 / unbalanced / phone jack
Front Panel
Front Panel knob
Table 7: Output Resolution (50 and 60Hz)
720x480 852x480 1024x768 1280x768
800x600 1280x960 1280x1024
1360x768
1280x800 1400x1050 1600x1200 1680x1050
1366x768 1920x1080 1920x1200 2048x1080
TabLE-8: General Purpose Interface I/O
Number
On VPM
On CPM
Inputs
8, assignable to input or
output
8, assignable to input or
output
Outputs
8, assignable to input or
output
8, assignable to input or
output
Connector
DB9
RJ50 to DB9
