Page 24 of 67
Tahoma LE-20 / LE-24 / LE-28 / LE-32
Table 14: Tahoma LE-20 / LE-24 / LE-28 / LE-32 Physical Specifications
Size
H: 3.50 in (8.9 cm, 2RU), W: 18 in (21.6 cm),
D: 13 in (33 cm)
Rack installation Standard 19-inch equipment rack.
Weight 25 lbs. (2.8kg)
Power 90/250 VAC, 60/50Hz, 200 W, internal auto
switchable
Noise Level Maximum 41dB. Tahoma LE has temperature
sensor to regulate fan speed, actual noise
level may be much lower
Figure 7 - 8 shows the front and back panels of the Tahoma LE-32.
Figure 7: Tahoma LE-32 front panel view
1. Signal presence LED
2. Power supply status
3. Audio volume adjustment
4. Audio phone jack output
5. Paging mode
6. Buttons to recall presets
