19 Appendix
B - mediaHUB Technical Reference
Video Inputs
- Composite (BNC)
- S-Video (4 Pin Mini-Din YC) analog to digital conversion 9 bit with scaling Horizontal and
Vertical 16 tap filters.
- (Option) SDI input video with embedded SMPTE 259M AES-EBU audio on BNC.
- (Option) Firewire: DV25 with PCM audio and control on Mini-Firewire connector.
Video Outputs
- One decode configurable to DVI-I,
S-Video (4 Pin Mini-Din YC), Composite (BNC).
Cable required for VGA, YUV, HDMI, RGBHV and RGB.
VBI Support
- Line 21-Closed Captioning DVS053 Rev 6
- V-Chip DVS157
- Teletext: NABTS-DVS053 Rev 6 and PAL
- Neilson Source Identification (SID) DVS053
- Automated Measurement of Lineups (AMOL) DVS053
Video Encoding and Decoding
- MPEG 1 SD 1 Profile: SIF ISO 11172-2
- MPEG 2 SD 2 Profile: Adaptive Field Frame (AFF) ISO13818 MP@ML
- MPEG 2 SD Profile: AFF ISO13818 422P@ML (encode only option)
- Encoder Filters: Temporal; Spatial Vertically and Horizontally Temporal and Horizontal
Spatial can be concurrent
- Chroma filtering and full scaling
- Video bit rates: MPEG 2 SD 300K-15 Mbs
- Video bit rates: MPEG 1 SIF 300K-5 Mbs
- Multiplexing Formats: Program (MPEG 1) and Transport (MPEG 2)
- MPEG Program Specific Information (PSI) Table Compliance: PAT, PMT; All PIDs user
definable
- DVB Service Information (SI) Table Compliance: SDT, NIT; All PIDs user definable
- SCTE 35 Splice Point injection
Video Resolutions
- Per Macro Block (16x16) Note: Non-standard Vertical resolutions may adversely effect
STB decoders, PC decoders have more flexibility when scaling.
- Horizontal NTSC examples: 720x480 (Full D1 NTSC), 544x480, 528x480, 512x480,
496x480, 480x480, 352x480 (Half D1 NTSC).
- Vertical NTSC example: 720x 464
- Horizontal and Vertical example: 528x464 etc.
- PAL resolutions examples: 720x576 (FullD1 PAL), 720x560, 544x544 etc
Audio Inputs
- Analog Audio 1 Stereo Balanced (5 Pin Removable Screw Terminal)
- Analog Audio 2 Stereo (SAP) Balanced (5 Pin Removable Screw Terminal)
- User level control on Analog inputs
- AES-1 digital audio (PCM or uncompressed) for Dolby AC-3 channel 1,2 encoding (5 Pin
RST - 110 Ohm).
- AES-2 digital audio (PCM or uncompressed) for Dolby AC-3 channel 3,4 encoding (5 Pin
RST - 110 Ohm).
- SDI embedded with video per SMPTE 272M A, B, C, (BNC)
- Digital PCM audio via Firewire
- Audio inputs can be mixed, one Analog, one AES-EBU, or One AES-EBU and one SDI etc.
Audio Outputs
- encoder module has AES (110 Ohm) out of compressed bit stream or PCM audio during
encode (does not work after encode)
- decoder module simultaneous S/PDIF digital audio (RCA female) and unbalanced analog
stereo audio (L/R RCA female). Digital audio PCM at 16, 20 and 24 bps up to 5.1 channels
compressed.
- decoder module (3.5 mm) selectable between audio tracks 1 and 2 decode.
- decoder module fixed unity analog audio level output
Audio Encoding and Decoding
- Dolby Digital 2/0 or 1/0 (AC-3) encoding from analog, SDI embedded audio or AES
input.
- MPEG 1 Layer 1 Profile: ISO11172-3
- MPEG 1 Layer 2 Profile: ISO13818-3
- Audio Delay: Adjustable PTS delay up to 700 milliseconds
- 24 Bit A-D Conversion
- Audio Sampling: 16, 22.05, 24, 32, 44.1 and 48 KHz
- MPEG 2 Audio Bit Rate: 64-384 Kbs
- Dolby Digital AC-3 Bit Rate: 64-640 Kbs
mediaHUB Server
- Adtec optimized POSIX compliant embedded Linux 2.6 kernel
- 300 GB internal storage.
- Power: 70-240 VAC 50-60Hz and 65 Watts (20 Watts typical) of power.
- Size: 1RU rack mount chassis. 19” width, 1.75” height, 16” depth (48.26cm X 4.45cm X
40.64cm)
- Weight: 14 lbs (6.35kg)
- Environmental: Active cooling (Fans), 0 to 90 Degrees Fahrenheit, Less than 70% RH,
Non-Condensing
Communications
- Ethernet 10/100 (RJ-45) Half Duplex, Full Duplex, Auto Negotiate
- Ethernet Protocols: Telnet and XCP Adtec command API, FTP, HTTP, SNMP (MIBII)
- Serial Communications: 2-RS232 (38400-115,200K, 8, 1 N)
- Samba, NAS and FTP file mounts or transfers
- Automatically copy files from mediaHUB server to client PC using FTP.
Front Panel
- Keypad: Mode, Select, Enter, Escape, Up, Down, Left, Right
- Blue Translucent LCD (20 character by 2 row)
- Host Status LEDs Power, Alarm, Link, Busy, Storage.
- Encode Status LEDs: Encode Active, Video Present, LTC Active, Audio 1 & 2, Control,
Alarm.
- Decode Status LEDs: Decode Active, Video Present, LTC Active, Audio 1 & 2, Control,
Alarm.
