Page 11
UM023902-1013
7
ZMOTION
®
20-Pin Detection and Control Development Kit
User Manual
•
Full-duplex UART with dedicated BRG
•
Two 16-bit timers with input capture, output compare and PWM capability (11 modes
total)
•
Watchdog timer (WDT) with dedicated internal oscillator
•
Up to 20 vectored interrupts
•
16 I/O pins
•
2.7 V to 3.6 V operating voltage with extended operating temperature range –40° C to
+105° C
•
Zilog PIR technology controlled and monitored via software API registers
•
Selection capability from an assortment of lenses and pyroelectric sensors to best fit
your application
•
API settings provided for each lens and pyroelectric sensor combination
•
Directly supports 1 or 2 pyroelectric sensors
•
Sensitivity control, range control and directionality detection
•
Extended detection modes for occupancy sensing
•
Low power modes
ZMOTION 20-Pin Detection and Control Development Kit
Lenses and Pyroelectric Sensors
The ZMOTION 20-Pin Detection and Control Development Kit includes nine different
types of lenses and three different types of pyroelectric sensors to fill a wide variety of
lighting control, occupancy sensing, HVAC, display, proximity and power management
applications. These applications also demonstrate the flexibility, and superior performance
of Zilog’s PIR motion detection technology.
Please refer to the
for part-specific details about the individual lenses and pyroelectric sensors.
Refer to the
fic installation instructions for the lenses and pyroelectric sensors.
Pyroelectric Sensor Options
The ZMOTION 20-Pin Detection and Control Development Kit includes the following
three pyroelectric sensors:
•
RE200B-P: a basic dual element sensor installed on the board
•
SDA02-54-P, a premium dual-element sensor
•
SBDI46-504AA, a quad-element sensor
