Signamax 065-1100NS/1110NS/1120NS Series
100BaseTX/FX Media Converter
Installation 13
Warning
Because invisible laser radiation may be
emitted from the aperture of the fiber port when no cable is
connected, avoid exposure to laser radiation and do not stare
into the open apertures.
Connecting Copper Cable
The 100BaseTX RJ-45 Ethernet port fully supports
auto-sensing and auto-negotiation.
1. Insert one end of Category 5 twisted pair cable into an
available RJ-45 port on the Converter and the other
end into the port of the network node.
2. Check the corresponding port LED on the Converter to
make sure that the connection is valid. (Refer to the
LED chart in the next section)
