Trulink data charting – Pengo TruLink User Manual
Page 15
PENGO TruLink Manual 15
Job Name:
PENGO TEST
Job Number: AQ1356
Customer:
PENGO
Location:
LAURENS, IOWA
Operator:
JON DAVIS
Machine:
CAT 320B
Date
Time
Pile Number
Torque
Depth
X Inclinometer
Y Inclinometer
25/01/2013
12:20:12
101
115
0
0
0
25/01/2013
12:20:13
101
222
0
0
0
25/01/2013
12:20:14
101
677
0
0
0
25/01/2013
12:20:15
101
4740
0
0
0
25/01/2013
12:20:16
101
6485
0
0
0
25/01/2013
12:20:17
101
13015
0
0
0
25/01/2013
12:20:18
101
16756
0
0
0
25/01/2013
12:20:19
101
18456
0
0
0
25/01/2013
12:20:20
101
22924
0
0
0
25/01/2013
12:20:21
101
25317
0
0
0
25/01/2013
12:20:22
101
28151
0
0
0
25/01/2013
12:20:23
101
29895
0
0
0
25/01/2013
12:20:24
101
32183
0
0
0
25/01/2013
12:20:25
101
34759
0
0
0
25/01/2013
12:20:26
101
37106
0
0
0
25/01/2013
12:20:27
101
39272
0
0
0
25/01/2013
12:20:28
101
41105
0
0
0
25/01/2013
12:20:29
101
42885
0
0
0
25/01/2013
12:20:30
101
44578
0
0
0
25/01/2013
12:20:31
101
46294
0
0
0
25/01/2013
12:20:32
101
48020
0
0
0
25/01/2013
12:20:33
101
49909
0
0
0
25/01/2013
12:20:34
101
54457
0
0
0
25/01/2013
12:20:35
101
58119
0
0
0
25/01/2013
12:20:36
101
62238
0
0
0
25/01/2013
12:20:37
101
66220
0
0
0
25/01/2013
12:20:38
101
68521
0
0
0
25/01/2013
12:20:39
101
70791
0
0
0
TRULINK DATA CHARTING
DATA CHARTING (RAW DATA)
Below is an example of the raw data recorded by the TruLink system and opened with Microsoft Excel. This data has
not been formatted or manipulated. This is the recorded data in its raw format.
Note: Torque and Depth values will be recorded in the units selected by the user. The default units are Ft/lbs
and Feet.
Pile Depth
(Entered by Operator)
Torque Value
(Ft/Lbs)
Date
(DD.MM.YY)
Time
(HH:MM:SS)
Job Information
(Entered by Operator at beginning of install)
Pile Angle
(Shown in X & Y)
