P/N: 4809645
©2006 Paxton Automotive
All Rights Reserved, Intl. Copr. Secured
16JAN06 v1.2 SRT-10(4809645v1.2)
4PCV130-026 OIL FEED ASSY 1
7P125-004 1/8"NPT 90° x -4 JIC FTG STL 1
7P125-005 1/8"NPT STR. x -4 JIC FTG STL 1
7P125-034 1/8"NPT x 1/8"NPT STRT TEE 1
7U100-055 TIE-WRAPS, 7.5" NYLON 10
7U250-000-220 OIL FEED HOSE, 22" -4 1
4PCV130-036 OIL DRAIN ASSY 1
7P375-017 3/8" x 1/2" BEADED HSE BARB FTG 1
7R001-008 # 8 STNL HOSE CLAMPS 2
7U030-036 1/2" OIL DRAIN HOSE 1.75'
7T560-001 CUTTER, 9/16" ROTOBROACH 1
7T 560- 002 ARBOR, ROTOBROACH 1
7U100-066 TIE-WRAPS, 11" NYLON 2
21016430 SUPERCHARGER ASSY 1
1016430 S/C ASSY 1
4PCS037-285 2.85" S/C PULLEY 1
4PCS111-044 S/C MTG PLT ASSY
4PSC010-044 S/C MOUNTING PLATE 1
4PCS010-034 S/C SUPPORT PLATE 1
4PCS017-011 SPACER IDLER PULLEYS 3
7A375-166 STUD SPACER, SRT10 1
7A375-175 3/8-16 x 1.75" HXHD BOLTS 3
7A375-250 3/8-16 x 2.5" HXHD BOLTS 5
7A375-276 3/8-16 x 2.75" HXHD BOLTS 2
7A375-278 3/8-16 x 2.75" CSHD 1
7A375-451 3/8-16 x 4.50" HXHD BOLTS 3
7F375-017 3/8-16 NYLOCK NUT 1
7A375-500 3/8-16 x 5.0" 1
7A312-525 5/16-18 x 5.25" HXHD BOLTS 2
7A312-500 5/16-18 x 5.00" HXHD BOLTS 2
7K375-030 3/8"AN WASHERS 18
7K312-001 5/16"AN WASHERS 2
2A017-010 SPACER 1
2A017-754-04 1.677" x .75" x .386" SPACERS 6
2A017-754-05 1.543" x .75" x .386" SPACERS 8
2A017-754-03 1.625" x .75" x .328" SPACERS 2
4FU116-031 IDLER PULLEY SMOOTH 1
4GV016-150 7-RIB IDLER PULLEY 1
4PCS116-150 90mm SMOOTH PULLEY 1
2A040-011 IDLER PULLEY RETAINERS 3
2A047-110 GATES 1
8PN105-060 WATER TANK MTG ASSY
8N055-030 SURGE TANK 1
8N055-050 SURGE TANK CAP 1
4PCS010-110 BKT MTG COOLANT RES 1
7P375-075 3/4" HOSE BARB UNION BRASS 1
7P500-026 1/2" x 3/4" BARB 90° FITTING 4
7R007-001 NYLON RATCHET CLAMP 1-1/8" 8
7U038-000 3/4" HEATER HOSE 17'
7U133-060 3/4" HOSE (TANK-PUMP) 1
7U038-012 HOSE Ø3/4" x 90° 1
7A250-050 1/4-20 .75" HXHD 2
7A250-051 1/4-20 x .50" SCHDCP SCREW 1
7E010-075 12 x 3/4" SHT MTL SCREWS HXHD 2
7J006-093 6mm WASHERS 5
7U100-066 TIE-WRAPS, 11" NYLON 5
8PN106-060 WATER COOLER ASSY
8N006-010 SINGLE PASS HT EXC 1
7P500-026 1/2" x 3/4" BARB 90° FITTINGS 2
7R007-001 NYLON RATCHET CLAMPS, 1-1/8" 2
4PCS010-010 HEAT EXCH MOUNTING BRKT “R” 1
4PCS010-020 HEAT EXCH MOUNTING BRKT “L” 1
4PCS010-030 HEAT EXCH BRKT SPACERS 2
7A250-126 1/4-20 x 1.25" HXHD 5
7F250-021 1/4-20 NYLOC PLT 5
7J006-093 6mm WASHERS 16
8N107-150 WATER PUMP ASSY C5 1
8PN301-068 CAC, WELDED ASSY
8PN103-030 INLET DUCT, CAC 1
8N003-090 DISCHARGE DUCT, CAC 1
8N201-001 WELDED COOLER CORE 1
4PCS112-028 DISCHARGE ASSY
4PCS012-020/21/28 DISCHARGE DUCT T-BODY 1
4PCS012-041/048 DISCHARGE DUCT 1
4PCS010-040 CAC SUPPORT BRKT 1
7U250-200 TAPE, FOAM 1/4" x .250 1'
7U038-012 HOSE Ø3/4" x 90° 4-11" 1
7P500-026 1/2" x 3/4" BARB 90° FTG 1
7P156-082 5/32" VAC TEE 3
7P375-250 3/8" x 3/8" x 1/4" VAC TEE 1
7U100-065 GROMMET .5"ID x .812"OD .187" GRV 1
7U030-046 5/32" VAC HOSE 15.0'
8H040-175 FILTER RACE BYPASS 1
7PS300-200 SLEEVES, 3.00" x 2.0"L 2
7PS350-200 SLEEVE, 3.5" x 2.0"L 1
7PS400-200 SLEEVE, 4.0" x 2"L 1
7PS450-200 SLEEVE, 4.5" x 2"L 1
7R002-048 CLAMPS 4
7R002-056 CLAMPS 2
7R002-064 CLAMPS 2
7R002-072 CLAMPS 2
4PCS212-018 AIR INLET ASSY
4PCS012-011/018 CAST ELBOW MODIFIED 1
4PCS013-010 AIR FILTER ENCLOSURE 1
4PCS010-060 AIR FILTER FLANGE 1
4PCS110-060 A/F MOUNTING FLANGE ASSY 1
8H040-400 AIR FILTER 1
7R002-060 HOSE CLAMPS #60 2
7R002-064 HOSE CLAMPS #64 2
7U035-003 FLEX HOSE 4.0" 2'
7A250-074 1/4-20 x 0.75" HXHD BOLTS 4
7F250-021 NYLOC NUTS 4
7J006-093 6mm WASHERS 8
7PS400-200 4.0" SLEEVE 1
7P500-001 1/2" HOSE UNION 1
7U030-050 1/2" FUEL HOSE (12mm) 2'
7P375-055 3/8" x 90° x 1/2" HOSE BARB 1
7P375-113 PVC 1
7P???-??? 1/2" x 3/8" REDUCER 1
7U030-056 3/8" PVC/VAC HOSE 6"
5A001-071 ECU 1
8D204-010 RACE BYPASS ASSY 1
4PCV101-001 FUEL SYSTEM 1
5W001-005 3/8" WIRE LOOM 6'
5W001-011 16-14 GA RING TERMINAL 2
5W014-030 14GA STRDWIRE BLACK 8"
7E010-075 # 12 x 3/4" SHT METL SCRW HEX 4
7P312-005 5/16" FEM FUEL CNCT STEEL 1
7P312-007 FUEL FTG 5/16" GM x 5/16" HSE 1
7P312-017 5/16" HOSE BARB TO M10 x 1.0" 2
7P312-082 5/16" TEE HOSE BARB 4
7R003-027 ADEL CLAMP 1-11/16" 1
7R004-001 STEPLESS CLAMP 15.77.70 22
7U031-018 5/16" EFI FUEL HOSE 8'
7U100-044 TIE-WRAP, 4" NYLON 10
7U100-055 TIE-WRAP, 7.5" NYLON 5
8F001-002 WALBRO IN-LINE F/P w/FTG 2
4PCS238-068 FMU ASSY SRT10 TRUCK 1
6Z001-001 DECAL PAXTON 1
6Z010-101 FMU HOUSING 1
6Z010-111 FMU VALVE BODY 1
6Z010-132 COVER w/SPRING 1
6Z020-130 SML DIAPHRAGM 1
6Z020-140 LG DIAPHRAGM 1
PART NO. DESCRIPTION QTY. PART NUMBER DESCRIPTION QTY.
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages or damaged
parts immediately.
2004/2005 Dodge SRT-10 Truck
Part No. 1201230-P
PARTS LIST
