KIT
, FUEL CONTROL
APPR.
-----
-----
86-93 5.0L MUST
ANG GT
-----
-----
-----
-----
1300 BEACON PLACE OXNARD, CA 93033
TEL: (805) 604-1336 F
AX: (805) 604-1337
CAD GENERA
TED DRA
WING,
DO NOT MANUALL
Y UPDA
TE
-----
-----
NOTES: UNLESS OTHERWISE SPECIFIED
1. TO BE SHIPPED LOOSE
2
10
4
TO FUEL RAIL
TO GAS T
ANK
3
11
TO VEHICLE FIREW
ALL
QTY
.
2
1
1
2
1
1
1
1
1
ITEM NO.
2
3
4
6
7
8
9
10
11
DESCRIPTION
SCREW
, #10-24 x .75 P
A
NHD SL
T SHTMTL, GR5
ASY
, FUEL LINE INLET
, FEMALE
ASY
, FUEL LINE OUTLET
, MALE
WRAPS, NYLON TIE 5.50 LG
INST
ALLA
TION INSTRUCTIONS FCU
TOOL, SPRING LOCK CPLR
TOOL, SPRING LOCK CPLR
PA
R
T
N
O
.
7E010-048
1018900
1019000
7U100-055
4822100
7T375-001
7T312-001
1211800-TOP
7U030-218X81
