Mcu programmer pin header mcu com port, Mcu programmer pin header, Mcu com port – NEXCOM VTC 7100-C8SK User Manual
Page 43
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
29
Chapter 3: Jumpers and Switches
VTC 71-C Series User Manual
MCU Programmer PIN Header
Connector location: JP2
Pin
Definition
Pin
Definition
1
+3.3ALW
2
C2D
3
MRST
4
C2CK
5
GND
MCU COM Port
Connector location: JP3
Pin
Function Description
1
TX
2
RX
3
GND
1
3
1
5
