Hardware Specifications
VTC 7100-C8SK/ 7110-C4SK/ 7120-C4SK
CPU
▪ VTC7100 series: Intel
®
Atom™ D2550 1.86GHz
▪ VTC7110 series: Intel
®
Core™ i7 2610UE 1.5GHz
▪ VTC7120 series: Intel
®
Celeron
®
847E 1.1GHz
Main Chipset
▪ VTC7100 series: ICH10R
▪ VTC7110 series: QM67
▪ VTC7120 series: QM67
Memory
▪ VTC 7110 and VTC 7120 series: One 204-pin SO-DIMM DDR3 1333 up to 8GB
2GB (default)
▪ VTC 7100 series: One 204-pin SO-DIMM DDR3 1066 up to 4GB
2GB (default)
Expansion
▪ 1x Mini-PCIe socket (PCIe + USB) for WLAN option
▪ 1x Mini-PCIe socket (USB) for WWAN option
▪ 1x Bluetooth module for option
▪ 1x on board uBlox NEO-6Q GPS module or optional GPS module with dead
reckoning
I/O Interface-Front
▪ 1x Line-out, 1x Mic-in (for WWAN CM8000 voice communication)
▪ 2x SIM card socket (selectable)
▪ 1x System reset button
▪ 1x USB 2.0 host type A connector
▪ 1x Power button
▪ 1x CFast with protection cover
▪ 2x Accessible 2.5” SATA II SSD tray
▪ 4x LED’s for power, storage, WLAN/ WWAN and GPIO
I/O Interface-Rear
▪ 1x 9~36VDC input with Ignition
▪ 1x 12V/4A DC output, SMBus
▪ 1x DB26 LVDS interface with 12V and USB2.0
▪ 1x DB15 VGA
▪ 1x DB9 RS-232 (default) or OBDII (optional)
▪ 1x DB9 RS-422/ 485
▪ 1x DB9 female connector for 4x DI and 4x DO
(Digital Input)
Input Voltage (Internal Type): 5VDC TTL (default)
Input Voltage (Source Type): 0~30 VDC
(Digital Output)
Digital Output (Sink Type): 5VDC TTL (default), max current: 20mA
Digital Output (Source Type): 0~30VDC, max current: 250mA
▪ 2x USB 2.0 host type A connector
▪ 2x RJ45 with LEDs for 10/ 100/ 1000Mbps Ethernet
▪ VTC 7110/7120 series: Supports 4x RJ45 with LEDs for 10/ 100/
1000Mbps Ethernet and support IEEE802.3af PoE, Max. 60W
▪ VTC 7100 series: Supports 8x RJ45 with LEDs for 10/ 100/
1000Mbps Ethernet and support IEEE802.3af PoE, Max. 60W
▪ 1x Line-out, 1x Mic-in
▪ 1x SMA-type GPS antenna connector
▪ 4x Antenna hole reserved for SMA-type antenna connector (WWAN/
WLAN/ BT)
Others
▪ 1x PCI-104
▪ 1x G Sensor
Note: If PCI-104 card & 2.5” SSD installation are required, 2.5” SSD will be internal type
and front panel will be changed.
