Removing the Chassis Cover
2. Lift the cover upward then remove it from the chassis.
Prior to removing the chassis cover, make sure the unit’s power is off and disconnected from the power sources to prevent electric shock or system damage.
1. The screws on the chassis are used to secure the cover to the chassis.
Remove these screws and put them in a safe place for later use.
Front View
VTC 6201 Rear View
VTC 6201-M Rear View
CAUTION!
CAUTION!
CAUTION!
