Chapter 2: Jumpers and Connectors
Copyright © 2011 Nexcom International Co., Ltd. All Rights Reserved 20 VTC 6201 Series User Manual
MCU Programmer Connector
Connector size: 1x5 5-pin header, 2.54 mm
Connector location: JP3
Pin Definition Pin Definition
1 +3.3ALW 2 C2D
3 MRST 4 C2CK
5 GND
5 1
GAL Programmer Connector
Connector size: 1x6 6-pin header, 2.54 mm
Connector location: JP2
6
Pin Definition
1 VCC3_3
2 GND
3 TCK
4 TDO
5 TDI
6 TMS
1
Connector pin definition Connector pin definition
