VTC 6120 User Manual

Appendix B: Express-MV-SL9400 COM Express CPU Module

PPendix

B: ie

xPress

-mV-sL9400 Com e

xPress

CPu m

oduLe

Overview

Express-MV-SL9400 is a Type 2 COM Express Module that features Intel

GS45 and ICH9M-SFF chipset; switch supports Intel

Core™ 2 Duo SL9400

processor with 1066 MHz FSB. One DDR3 memory socket supports up
to 2GB. The Express-MV is integrated with Intel

Graphics Media Core

4500MHD and expands via PCI Express Graphics x16 lanes to the carrier
board. It also supports other display interfaces including LFP or Dual channel
LVDS.
The high performance Express-MV-SL9400 COM Express Module supports 2
x SATA, 8 x USB 2.0 and 4 PCIe x1 Lanes through the carrier board.

Key Features

• Intel

Socket M supports Core™ 2 Duo / Core™ 2 Duo LV Processor Family

• Intel

GS45 Chipset

• One DDR3 SO-DIMM socket supports un-buffered non-ECC DDR3

1066/1333MHz up to 2GB

• Supports 2 x Serial ATA for high speed drives, 8 x USB 2.0 for fast peripherals

• Type 2 COM Express Module supports up to 21 Express lanes, 32 bit PCI

interface, one IDE and Gigabit LAN
