VTC 6120 User Manual

Chapter 1: Product Introduction

COM Express CPU Module and Carrier Board

The VTC 6120 system uses the Express-MV-SL9400 COM Express CPU module
and the VTC 6120 carrier board.

Express-MV-SL9400 COM Express CPU Module

Express-MV-SL9400 is a COM Express CPU module that uses the Intel

GS45 and ICH9M-SFF chipset and supports Intel

Core™ 2 Duo SL9400.

The module also supports one unbuffered non-ECC hz1066/1333 MHz
DDR3 SO-DIMM with maximum memory size up to 2GB. The Intel

GS45

and ICH9M-SFF chipset supports the following interfaces: PCI, PCIe, SATA,
VGA, LVDS, LAN, Serial, USB, etc.

The Express-MV-SL9400 module is based on the COM Express basic form fac-
tor Type 2 standard, x2 connections between the COM Express CPU module
and the I/O carrier board.

VTC 6120 Carrier Board

Key features:

• Quick customizable COM Express architecture platform

• Wide varieties of built-in communication and I/O ports specially de-

signed for Transport Application

• Customizable delay time for power-on and power-off

• Three external serial port interfaces with two RS232 and one RS232/485

• Supports 10/100/1000 LAN,VGA Console, LVDS and GPIO

• 3 x USB 2.0 ports

• Supports PCI-104 expansion
