Chapter 4: BIOS Setup
H/W Monitor
This section is used to monitor hardware status such as temperature, fan
speed and voltages.
CPU Temperature
Detects and displays the current CPU temperature.
System Temperature
Detects and displays the current system temperature.
Fan1 Speed
Detects and displays Fan1 speed.
Advanced
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Pc Health Status
CPU temperature
System temperature
Fan1 Speed
Fan2 Speed
VCORE
+3.3V
+5V
+12V
: +32C
: +32C
: N/A
: N/A
: +0.848 V
: +3.328 V
: +5.017 V
: +11.932 V
Fan2 Speed
Detects and displays Fan2 speed.
VCORE
Detects and displays the Vcore CPU voltage.
3.3V
Detects and displays 3.3V voltage.
5V
Detects and displays 5V voltage.
12V
Detects and displays 12V voltage.
