NISE 3640E Series User Manual
Chapter 2: Jumpers and Connectors
Jumpers
ME Pin Header
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP5
Pin
Definition
1
SRTC_RST#_PU
2
SRTC_RST#
3
CLR_ME
COM4 RS232 RI# Pin Power Select
Connector type: 1x3 3-pin header, 2.0mm pitch
Connector location: JP12
Pin
Definition
1
VCC5_RI#
2
SP4_RI_T
3
+12V_RI#
4
SP4_RI_T
5
SP4_RI
6
NA
1
3
1
5
