Wireless Ethernet PtP & MP System Operations Manual
INDEX
PREFACE P1-P2
KBC WES Part Numbers & Included Products in WES Kits P1
KBC Technical Support Availability P2
INDEX i
GOVERNMENTAL & SAFETY INSTRUCTION ii-v
Important Safety Instruction ii
FCC Required Information and Radio Frequency Statement iii
FCC and IC Restrictions iv
Environmental Restrictions v
SET UP & SYSTEM OVERVIEW 1-9
WES Set Up 1
FCC Regulatory Alert 2
WES Details – Physical Description & Diagram: Directional WEM 3
WES Details – Physical Description & Diagram: Omni-directional WEM 4
Power Injector Details – Physical Description & Diagram
4
WES LED Patterns 5
WES Cable Connection Diagrams 6
WEM Installation & Operation 7-8
Locator Software Tool Orientation & Operation 9
ADVANCED OPERATION – INTERNAL WEB BROWSER GUI 10-19
Log In
Reaching the GUI and determining the default GUI password
10
Status – Device Status
learn the parameters of the wireless and Ethernet configurations
10-11
Status – Host/Client Association Lists
Important signal strength information
12
Status – Statistics
Information regarding Ethernet packet & WES traffic stats
13
Basic – Wireless
Wireless and encryption method reconfiguration instructions
14-15
Basic – Ethernet
Info in order to change static or DHCP subnet and gateway settings
16
Advanced – Admin
Administrator password and device name reconfiguration instructions
17
Advanced – System
Restoring to defaults using the internal GUI web browser pages
18
Advanced – Firmware
Current firmware level & uploading firmware upgrade files
19
SPECS / APPROVALS / TROUBLE-SHOOTING / WARRANTY 20-24
WES Configuration Table 20
Node Specifications & FCC/IC Approvals 22-24
Trouble-shooting 25
Warranty Information 26
APPENDIX A1-A2
i
Wireless Ethernet PtP & MP System Operations Manual
IMPORTANT SAFETY INSTRUCTION
For your protection, please read and observe all safety instructions before operating
this system and keep this sheet and any additional instructions for future reference.
INSTALLATION & USE
OBSERVE WARNINGS: All warnings in the operating instructions should be carefully
followed. Do not make any modifications to the Wireless Ethernet Module (WEM),
Power Injection Module (PIM), or any other KBC electronic device, as the unit(s) will
no longer comply with FCC regulations and therefore void its warranty.
WATER AND MOISTURE: The WEM is weatherproof provided it is installed in
accordance to the mounting details listed on page 7. However, further protection or
housing is suggested for harsh environments, as moisture damage voids its
warranty. The PIMs used in this system are NOT weatherproof. None of the
modules in this system are waterproof and should never be submerged. Severe
electrical shock, personal injury or damage to the equipment may result.
POWER SOURCE: Connect the equipment to a power source only of the type
described on the operating instructions or as marked on the equipment. Excessive
or insufficient amperage or voltage can cause extended trouble-shooting or even
damage that could negate its warranty. The power supplies’ cable should not be
modified/extended due to the ability to use up to 100 meters of power over Ethernet
cable. In addition, Ethernet cable running from the PIM to the WEM should be kept
separated from high-voltage cables and/or transformers.
ATTACHMENTS: Use only KBC supplied or recommended Power Injection Modules,
Power Supplies, Cat5 Cables and weather seals and plugs.
WHEN NOT IN USE: Unplug the power if the equipment is left unattended or unused
for long periods of time or during lightning storms.
REPLACEMENT PARTS: When replacement parts are required, use only replacement
parts specified by KBC. Unauthorized substitutions may result in damage to the
system and could void the warranty.
