Wireless Ethernet PtP & MP System Operations Manual
ADVANCED OPERATION (CONTINUED)
G. ADVANCED – SYSTEM
To reboot the system and/or bring to default settings, visit the system page of the
Advanced tab.
SYSTEM COMMANDS
Reboot to save any changes applied while reconfiguring the system. A reboot
button appears after a saved change so it is not required to come to the
Advanced/System page of the interface.
If the firmware is updated, a restore to defaults may be necessary. Defaults are as
follows:
GUI Password: admin (all lower case)
LAN IP: 192.168.1.200 (Host); 192.168.1.201 (Client)
Subnet Mask: 255.255.255.0
Gateway: 192.168.0.1
Frequency Selection: Use Rotary Switch (which ever channel selection is made on
the switch)
Super Mode: Disabled
Encryption & Cipher: WPA-2; AES
Device Name: WES SP Host; WES MP Host; WES Client (depends on software type)
18
Wireless Ethernet PtP & MP System Operations Manual
ADVANCED OPERATION (CONTINUED)
H. ADVANCED – FIRMWARE
This page is used to flash firmware updates when necessary.
FIRMWARE INFORMATION
Current firmware is 7.06 for all units using channel selector switches that have 8
positions (0-7). Current firmware for older 10 position (0-9) switches is 7.05
FIRMWARE UPGRADE
If you receive a firmware update file from KBC, save to an accessible
place to upgrade when connected to the unit. Click “Browse” and double-
click the saved file. Then click “Upload”. Wait for the timer to count down
as the upgrade process takes place. Then re-access the device on its
former IP address. Click “Advanced” and then “System” and restore the
unit to factory defaults (see previous page 18) for default configurations.
19
