1.2 Identifing Parts
Take a moment to familiarize yourself with the parts of
RTX. This will help you to better understand the following
instructions.
Ejection Handle
1. Pre-Installation Steps 2
1.1 Box Contents 2
1.2 Identifying Parts 2
1.3 Warnings and Notices 3
2. Installation Steps 4
2.1 TrayFree Bay Drive Installation 4
2.2 Drive Installation for RTX with Removable
Carriers
4
2.3 Host Connections 4
3. Operation Steps 4
4. Write Portection Mode Selection (QJp model only) 4
5. LED Behavior 4
5.1 RTX220-3SJ 4
5.2 RTX221-3SJ and RTX222 Secure-3SJ 4
5.3 RTX220-QJ 5
5.4 RTX221-3QJ and RTX222 Secure-3QJ 5
5.5 RTX220-3QJp 5
5.6 RTX221-3QJp and RTX222 Secure-3QJp 5
6. Usage with Mac and Windows Operating
Systems
5
6.1 Usage with Mac OS X 5
6.2 Usage with Windows Operating Systems 6
7. Encryption (Secure models only) 7
8. Technical Specifications 8
Table of Contents
1. Pre-Installation Steps
1.1 Box Contents
Depending on which configuration and accessories you
purchased, the package may include fewer items than
what are listed here. Please contact CRU if any items are
missing or damaged:
RTX Unit 1
USB 3.0 A to B cable 2
eSATA cable (RTX-3QJ and RTX-3QJp only) 2
FireWire 800 cable 2
Power cord 1
Packet of keys for locks 1
Encryption keys (Secure models only) 4
Quick Start Guide and Warranty Info 1
Front of RTX-3SJ
Drive
Power
LED
Drive
Activity
LED
Key
Lock
Rear of RTX-3SJ
USB 3.0 Port
eSATA /USB 2.0
combo Port
60mm
exhaust
fan
Power
Switch
AC power
inlet
