OPTIM SERIES
18
Table 7-4.- Nominal consumption of the capacitors, according to the power
Power
CURRENT
230 V 400 V
In In
2.5 kvar 6.28 A 3.6 A
5 kvar 12.56 A 7.2 A
7.5 kvar 18.85 A 10.8 A
10 kvar 25.12 A 14.4 A
12.5 kvar 31.41 A 18 A
15 kvar 37.7 A 21.6 A
20 kvar 50.24 A 28.8 A
25 kvar 62.82 A 36 A
30 kvar 75.4 A 43.2 A
40 kvar 100.48 A 57.6 A
50 kvar 125.64 A 72 A
60 kvar 150.8 A 86.4 A
70 kvar 175.92 A 101.1 A
80 kvar 200.96 A 115 A
NOTE: If the consumption is below ±25%, and the voltage is normal, this is usually a symptom of
degradation of the capacitors. In case this is detected in a capacitor, it should be replaced with
another capacitor.
7.3.3 Regulator Checks.
Refer to the manual of the specific regulator used in the battery. This manual is
always supplied with the bank.
• Check that there are no faulty segments on the display.
• Check that the keyboard is operating properly:
- Enter Setup and check the adjusted values
- Force the manual connection and disconnection of a step.
7.4 Environmental Conditions:
• Check that the maximum environmental conditions listed in section 4.3 are observed
