Casella CEL-35X dBadge Users Handbook – Page 13
5 GENERAL OPERATION
5.1 Switching on the dBadge
Once the instrument is switched on by pressing the „L‟ key, it will
display a start up sequence, shown in Figure 8. This displays the
dBadge model number and firmware version (e.g. V1.07), followed by
the „Custom Text‟ screen. This text can be configured using the
Casella insight data management software. The screen will then
change to the current time and date. This will automatically be set to
the internal clock of the PC every time the dBadge is downloaded to
Casella insight data management software.
CASELLA
CEL-350
V1.01
Figure 8
The next screen shows the remaining battery life and memory as
shown in Figure 9. The caution symbol will be displayed on the left
of the display if remaining memory or battery life are under 2 hours.
The next screens show the instantaneous sound pressure level (SPL)
currently being measured by the microphone and the current clock
time set within the instrument.
Figure 9
JOE BLOGGS
CONSULTANTS
23 JUL 05
13:45:03
LAF 112.3
13:45:03
dB
7
Hrs
80
Hrs
Screen will show CEL-
350L on dB
adge „Lite‟
model or CEL-352 on
dB
adge „Plus‟ model.
