CEL-63x Environmental & Occupational Noise Meter

Casella CEL

Octave or 1/3 Octave Period Result line :-

If the 1/1, 1/3 Octave L

is enabled and the meter has octave or third octave

filters then an Octave Period result line is output with 11 x Octave band L

eqs

or a

third octave Period result line is output with 33 x 1/3 octave L

eqs

These are in format:-

<1/1 OCT LwEQ>, YYYY-MM-DD, HH:MM:SS, freq1, value1, freq2,
value2…freq11, value11

<1/3 OCT LwEQ>, YYYY-MM-DD, HH:MM:SS, freq1, value1, freq2,
value2….freq33, value33

Where LwEQ = L

ZEQ

CEQ

or L

AEQ

depending on the setup octave weighting e.g.

<1/1 OCT L

Ceq

>, 2010-05-07, 15:23:45, 16Hz, 32.4, 32Hz, 67.2......... 16 KHz,

54.2

<1/3 OCT L

Ceq

>, 2010-05-07, 15:23:45, 12.5Hz, 32.3, 16Hz, 43.2.... 20 KHz,

32.7

NOTE
„Environmental 2‟ setup should be selected when used with the Multi Agent Monitor
(MAM), see MAM operator instructions for further details.

RS232 Data Format

The online mode uses 1 start bit, 8 data and 2 Stop bits with NO parity with a
baud-rate between 1200 and 115,200. Ensure that the receiver is set to the same
baud-rate and data format.

The Comma Delimited ASCII data format can be directly input into a standard
terminal emulation program (e.g. Microsoft HyperTerminal) and can be saved
as a standard text file which can be exported to most spread sheets e.g. excel.
