Delta Electronics FHS-A7015B40 - Manual (Page 3)

Heat sink ·
·
·
Thermal interface material
Fan (70 x 70 x 15 mm)
. Type: Extrusion
Material: Aluminum 6063 or Equivalent.
Dimension: 77
68.5 41.2 mm
Material: Dow Corning SC102 or Equivalent.
Life Time:
one ball one sleeve bearing 40000 hrs
two ball bearing 70000 hrs
Connector:
a..Lead wire: UL 1007 AWG#24
pin 1: black wire--------(-)
pin 2: red wire----------(+)
pin 3: blue wire---------(F00)
b. Housing: Molex 2695-03 22-01-3037 or equivalent
c. Terminal: Molex 2759t 08-50-0113 or equivalent
x x
·
·
·
Thermal resistance: 0.28
Heatsink Weight: 290 g (ref,)
Clipping Force: 32.0 Kgf (ref.) o C/W (ref.)
· AMD Socket 754 K8 (Athlon 64)
Application:
Noise
(dBA)
ca
(
C
/W)
Speed (rpm)
Thermal Resistance Noise (dBA)
Thermal & Mechanical Specification:
Component Specification:
DELTA PRODUCTS CORPORATION
4405 CUSHING PARKWAY
FREMONT, CA 94538, U.S.A.
TEL : 1-510-668-5100
FAX : 1-510-668-0680
DELTA ELECTRONICS, INC.
252, SHANG YING ROAD, KUEI SAN,
TAOYUAN HSIEN 333, TAIWAN, R.O.C.
TEL: 886-3-3591968 EXT.2060
FAX: 886-3-3591991
DELTA ELECTRONICS EUROPE LTD.
2 YOUNG PLACE
KELVIN INDUSTRIAL ESTATE
EAST KILBRIDE, GLASGOW G75 OTD, U.K.
TEL : 44-1355-588888
FAX : 44-1355-588889
DELTA ELECTRONICS (JAPAN) INC.
DELTA SHIBADAIMON BUILDING
2-1-14 SHIBADAIMON, MINATO-KU,
TOKYO, 105-0012, JAPAN
TEL : 81-3-5733-1111
FAX : 81-3-5733-1211
* All readings are typical values at rated voltage.
* Specifications are subject to change without notice.
FHS-A7015A42/FHS-A7015B42
286A0404
0.270
0.280
0.290
0.300
0.310
0.320
0.330
0.340
0.350
0.360
2500 3500 4500 5500 6500
20
25
30
35
40
45
