Delta Electronics EHB Series User Manual

Dimensions drawing p & q curve, Mounting panel cutout

background image

172 x 150 x 50.8 MM SERIES

EHB

DIMENSIONS DRAWING

P & Q CURVE

(AT RATED VOLTAGE)

MOUNTING PANEL CUTOUT

Bearing Type
Ball Bearing
Material
Impeller : Plastic (UL 94V-0)
Frame:Die-Cast Aluminum
Lead Wires :
UL 1007 AWG #24 OR Equivalent
Red Wire Positive (+)
Black Wire Negative (-)
Weight : 800g (28.22 oz)

s

*

*

*

*

* Function type is optional.
* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
* Noise is measured in anechoic chamber in free air, one meter from intake side.
* All readings are typical values at rated voltage.
* Specifications are subject to change without notice.

Operating

Voltage

Range

MODEL

Rated

Voltage

Maximum

Air Flow

Input

Power

Input

Current

Speed

Maximum

Air Pressure

Noise

PART NO. FUNCTION VDC VDC Amp Watt R.P.M. CFM mmH O IN H O dB-A

2

2

EHB1548HHG

48

32.0

-R00 / -F00

to 80.0

0.61

29.28

4300

8.565

302.47

28.33

1.115

62.5

EHB1548VHG

-R00 / -F00

48

32.0 to 80.0

0.72

34.56

4600

9.235

326.13

32.87

1.294

64.5

EHB1548SHG

-R00 / -F00

48

32.0 to 80.0

0.88

42.24

4900

9.828

347.08

37.89

1.492

66.5

EHB1548EHG

-R00 / -F00

48

32.0 to 80.0

1.20

57.60

5200

10.608

374.62

43.27

1.703

68.5

OUTLET SIDE

INLET SIDE

http://www.deltaww.com

(INCH)

mm

UNIT:

SH

VH

2

2

EH

A

ir

P

re

s

s

u

re

(I

N

H

O

)

(m

m

H

O

)

0

0

0

0

0.4

0.8

10.0

20.0

1.2

1.6

30.0

40.0

2.0

50.0

(M /MIN)

Air Flow

300.0

5.0

200.0

100.0

2.5

7.5

12.5

400.0

10.0

(CFM)

3

EHB1548XXG

HH
