17
U
NDERSTANDING
LED I
NDICATORS
The front panel LEDs provide instant status feedback, and helps
monitor and troubleshoot when needed.
Figure 7. LED indicators of the Switch
System LEDs
POWER:
On : When the Power LED lights on, the Switch is receiving power.
Off :
When the Power turns off or the power cord has improper
connection.
Power Maximum (PWR MAX)
On : When the system power resource remain <=15.4W (the system
power consumption >= 155W), the LED will be on, the system
will not provide power to the additional POE PD inserted.
Off : When the system has enough power more then 15.4W (the
system power consumption <155W).
