ENGLISH
35
18 TROUBLESHOOTING
2 Are all the connections correct ?
2 Are you following the instructions in the manual ?
2 Are the amplifier and speakers operating properly ?
If the DN-C550R does not seem to be functioning properly, check the table below. If this does not solve the problem, the DN-
C550R may be damaged. Turn off the power, unplug the power cord from the power outlet, and contact your store of purchase or
nearest DENON sales office.
Symptom Check Page
7
–
No power.
Check Again Before Assuming The Player Is Malfunctioning
• Ensure that the POWER button is on.
• Ensure that the mains cable is plugged in correctly.
11
6
–
Auto track does not work.
• Check if auto track is selected.
• Check if there are 3 seconds silence in between the tracks.
• Check if the source is a consumer source with the digital output according to the IEC
audio standard.
–
–
No sound.
• Check the audio connections.
• If using an amplifier, try using a different source.
– Amplifier sound is distorted. • Check that the CD recorder analog output is not connected to the amplifier Phono input.
10
6
Play will not start.
• Ensure that the label of the CD is facing up.
• Clean the disc.
9
9
Remote control does not work.
• Point the remote control directly at the CD recorder.
• Check the batteries and replace if necessary.
6
–
5
7
6
16
8
Will not record.
• Clean the disc.
• Check if CD-R is an unfinalized disc.
• Check that the disc is recordable and replace if necessary.
• Check whether there is time remaining on the disc.
(“Disc Full” is displayed.)
• Check whether there is an attempt to digitally record a digitally recorded source.
(“Copy Prohibit” is displayed.)
• Check whether the recording level adjustment is suitable.
• Wrong input source chosen.
16 Recording is distorted. • Make sure the recording level is correct.
11 10 second pause between recordings. • See setting the synchro recording level.
–
“Disc Error” on the display.
A recorded CD-R disc cannot be played on
another player or CD unit.
• If then appears on the display, the disc cannot be recorded further, and cannot be
finalized. But it can still be played on the CD recorder or another CD recorder. “Disc
Error”
• Finalize the disc.
• Is playback possible on another CD player? If so, clean the pickup of the player on
which the disc could not be played.
• CD-R discs cannot be played on some CD players.
6, 27
–
–
Copying, recording, finalize and editing of
CD-R/RW is not possible.
• Is the relay mode set to “RELAY” or “MIX”?
Switch to “SINGLE” or “DUAL”.
24
19 MAIN SPECIFICATIONS
2 Audio: CD unit: CD-R unit (for digital editing)
Frequency response: 2 Hz to 20 kHz: 2 Hz to 20 kHz
Dynamic range: 98 dB: 88 dB
S/N ratio: 105 dB: 100 dB
Harmonic distortion: 0.003 % (1 kHz): 0.01 % (1 kHz)
Wow & flutter: Below measurable limits (±0.001 % W. peak)
Analog output (UNBALANCED)
Transfer and connector: Unbalanced, RCA jack
Output level: 1.7 Vrms, 10 k Ω /kohms
Headphone output: 0.3 mW (32 Ω /ohms)
Analog input (UNBALANCED)
Transfer and connector: Unbalanced, RCA jack
Input level: 1.7 Vrms, 47 k Ω /kohms
Analog input (BALANCED)
Transfer and connector: Balanced active, XLR connector (1. Common 2. Hot 3. Cold)
Input level: +18 dBs, 10 k Ω /kohms
Digital output (COAXIAL)
Transfer and connector: Unbalanced, RCA jack
Signal format: SPDIF or IEC-958 Type II
Digital output (OPTICAL)
Signal format: SPDIF or IEC-958 Type II
Digital input (COAXIAL)
Transfer and connector: Unbalanced, RCA jack
Signal format: SPDIF or IEC-958 Type II
Digital input (OPTICAL)
Signal format: SPDIF or IEC-958 Type II
2 Usable discs: CDs (12 cm/8 cm)
CD-R/RW Discs (CD-R unit)
2 General:
Power supply:
AC 120 V, 60 Hz
Power consumption: 29 W
Maximum external dimensions: 482 (width) x 88 (height) x 315 (depth) mm
(Not including feet, knobs and terminals)
Mass: 6.3 kg
2 Remote control unit: RC-278
Remote control system: Infrared pulse
Power supply: DC 3 V, using two R6P (AA) batteries
✽ Design and specifications are subject to change without notice in the course of product improvement.
Menu mode cannot be set.
Finalizing is not possible.
• Is the disc tray for the CD or CD-R section open? Close the disc trays for both the CD
and CD-R sections.
• Is the CD or CD-R section operating? Set the stop mode for both the CD and CD-R
sections.
27, 33
27, 33
